Product Summary

The x2g100sd12p3 is an aluminum electrolytic capacitor.



Parametrics

x2g100sd12p3 absolute maximum ratings: (1)Category Temperature Range: – 25 ~ +105°C; (2)Rated Voltage Range: 200 ~ 450V; (3)Rated Capacitance Range: 82 ~ 2200μF; (4)Capacitance Tolerance: ±20% at 120Hz, 20°C; (5)Leakage Current: I (μA)(After 5 minutes application of rated voltage)[C : Rated Capacitance (μF)V : Voltage (V)].

Features

x2g100sd12p3 features: (1)Long life assurance series withstanding 5000 hours application of rated ripple current at 105°C.; (2)Suited for rectifier circuit of general inverter, switching power supply.; (3)Adapted to the RoHS directive (2002/95/EC).

Diagrams

x2g100sd12p3 pin connection
