Product Summary
The 2mb1200s-120-50 is a signal conditioning 2:1 multiplexer and 1:2 fan-out buffer designed for use in backplane redundancy or cable driving applications. Signal conditioning features include input equalization and programmable output de-emphasis that enable data communication in FR4 backplane up to 4.25 Gbps. Each input stage has a fixed equalizer to reduce ISI distortion from board traces. It is ideal for: (1)Backplane driver or cable driver; (2)Redundancy and signal conditioning applications; (3)CPRI/OBSAI.
Parametrics
2mb1200s-120-50 absolute maximum ratings: (1)Supply Voltage (VCC ): -0.3V to 4V; (2)CMOS/TTL Input Voltage: -0.3V to (VCC +0.3V); (3)CML Input/Output Voltage: -0.3V to (VCC +0.3V); (4)Junction Temperature: +150°C; (5)Storage Temperature: -65°C to +150°C; (6)Lead Temperature Soldering, 4 seconds: +260°C; (7)Thermal Resistance, θ JA (Note 8): 26.2°C/W; (8)Thermal Resistance, θ JC-top: 3.3°C/W; (9)Thermal Resistance,ΦJB: 11.1°C/W; (10)ESD Rating (Note 10): HBM, 1.5 kΩ, 100 pF: 6 kv; CDM: 1.25 kv; MM: 350 v.
Features
2mb1200s-120-50 features: (1)2:1 multiplexer and 1:2 buffer; (2)0.25 – 4.25 Gbps fully differential data paths; (3)Fixed input equalization; (4)Programmable output de-emphasis; (5)Independent de-emphasis controls; (6)Programmable loopback modes; (7)On-chip terminations; (8)HBM ESD rating 5.5 kV on all pins; (9)+3.3V supply; (10)Lead-less LLP-36 package; (11)-40°C to +85°C operating temperature range.
