Product Summary

The fsb20ch60 is a 2 amp fast recovery bridge rectifier.



Parametrics

fsb20ch60 absolute maximum ratings: (1)Maximum DC Blocking Voltage: 1000 V; (2)Maximum RMS Voltage: 700 V; (3)Maximum Peak Recurrent Reverse Voltage: 1000 V; (4)Peak Forward Surge Current (8.3mS single half sine wave superimposed on rated load)IFSM: 50 A; (5)Maximum Forward Voltage at 1 Amp DC VFM: 1 V; (6)Maximum Average DC Reverse Current At Rated DC Blocking Voltage IRM: 500 μA; (7)Maximum Thermal Resistance, Junction to Ambient (Note 2)RJA: 30 °C/W; (8)Junction Operating and Storage Temperature Range TJ,TSTG: -55 to 150 °C.

Features

fsb20ch60 features: (1)PRV Ratings from 50 to 1000 Volts; (2)Surge overload rating to 50 Amps peak; (3)Reliable low cost molded plastic construction; (4)Ideal for printed circuit board applications; (5)Fast switching for high efficiency.

Diagrams

fsb20ch60 pin connection
