Product Summary

The 7mbi75sa-120b is an IGBT.

Parametrics

7mbi75sa-120b absolute maximum ratings: (1)Collector-Emitter Voltage: 600 V; (2)Gate -Emitter Voltage: +/-20 V; (3)Collector Current: 75 A; (4)Collector Power Dissipation: 320 W; (5)Operating Junction Temperature: +150°C; (6)Storage Temperature: -40 to +125°C; (7)Isolation Voltage: 2500 V; (8)Mounting Screw Torque: 3.5 Mn; (9)Terminal Screw Torque: 3.5 Nm..

Features

7mbi75sa-120b features: (1)including brake chopper; (2)square RBSOA; (3)low saturation voltage; (4)overcurrent limiting function ( 3 times rated current ).

Diagrams

7mbi75sa-120b dimension figure
