Product Summary

The f4-150r06kl4 is a Power Relay. It is ideal for：(1)ignition lock; (2)lamp load (headlights); (3)cooling fan; (4)abs; (5)exhaust emission control; (6)cross carline up to 60 a; (7)fuel pump; (8)engine cooling fan; (9)a/c blower– a/c compressor clutch; (10)also available for 42 v applications.




Parametrics

f4-150r06kl4 absolute maximum ratings: (1)available for nominal voltages: 12　to 24 v; (2)nominal power consumption of the unsuppressed coil at nominal voltage: 1.6 w; (3)nominal power consumption at nominal voltage with suppression resistor: 1.8/2.1 w (standard/high performance 24 v); (4)test voltage winding/contact: 500 vacrms; (5)ambient temperature range: – 40 to + 125 °c; (6)operate time at nominal voltage: typ. 7 ms; (7)release time at nominal voltage1）: typ. 2 ms.

Features

f4-150r06kl4 features: (1)limiting continuous currents 60/40 a at the no/nc contacts; (2)dimensional characteristics and the functional allocations of the plug-in terminals to iso 7588 part 1; (3)standardized dimensions; (4)24 v versions with contact gap > 0.8 mm; (5)plug-in or pcb terminals.

Diagrams

f4-150r06kl4 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
F4-150R06KL4
F4-150R06KL4
Infineon Technologies
IGBT Modules N-CH 600V 180A
