Product Summary

The 2mbi200l-120 is an IGBT MODULE. The applications of the 2mbi200l-120 include Inverter for motor drive, AC and DC servo drive amplifier, Uninterrptoble power supply, Industrial machaines, such as welding machines.

Parametrics

2mbi200l-120 absolute maximum ratings: (1)Collecter-emitter voltage, VCES: 1200 V; (2)Gate-emitter voltage, VGES: ±20 V; (3)Collecter current, IC: 200 A; (4)Max. power dissipation, PC: 1600 W; (5)Operating temperature, TJ: +150 ℃; (6)Storage temperature, TSTG: -40 to +125 ℃; (7)Isolation voltage, VISI: 2500 V; (8)Screw torque: 3.5 Nm.

Features

2mbi200l-120 features: (1)High speed switching; (2)Low saturation voltage; (3)Voltage drive.

Diagrams

2mbi200l-120 block diagram
