Product Summary

The MM5837N is a MOS pseudorandom sequence generator. The MM5837N designed to produce a broadband while noise sugnal for audio applications. Unlike tranditional semiconductor Junction niose sources, the MM5837N provides very uniform noise quality and output amolitude. The shift register starts at a random nonzero state when power is applied. The circuit is packaged in an 8-lead plastic DIP. The applications of the MM5837N include Electronic musical rhythm instrument sound generators, Music synthesizer white and pink noise generators, Room acoustics testing/equalization.

Parametrics

MM5837N absolute maximum ratings: (1)Optinal Gate Supply Voltage, VGG: -33 to 0.3 V; (2)Logic Supply Voltage, VDD: -25 to 0.3 V; (3)Storage Temperature, Ts: -55 to 100 ℃; (4)Operating Temperature, TA: 0 to 70 ℃; (5)Lead Temperature: 300℃.

Features

MM5837N features: (1)Uniform noise quality; (2)Uniform noise amplitude; (3)Electronic musical rhythm instrument sound generators; (4)Music synthesizer while and pink noise generators; (5)Room acoustics testing/equalization.

Diagrams

MM5837N block diagram
