Product Summary
The kbpc35-10 is a single phase silicon bridge.
Parametrics
kbpc35-10 absolute maximum ratings: (1)peak repetitive reverse voltage vrrm: 1200V; (2)rms reverse voltage (rms): 840V; (3)dc blocking voltage vdc: 1200V; (4)Average Forward Rectified Current IF(av): 40 A; (5)Non-Repetitive Peak Forward Surge Current IFSM: 400 A; (6)forward voltage vf: 1.1 V; (7)Isolation Voltage Case to Leads VISO: 2500 Volts AC; (8)DC Reverse Current IR Rated DC Blocking Voltage per Leg: 500 mAmps; (9)Typical Thermal Resistance RqJC Junction to Case per Leg: 1.9 °C / W; (10)Typical Junction Capacitance CJ: 300 pF; (11)Operating & Storage Temperature Range TJ, TSTRG: -55 to 150°C.
Features
kbpc35-10 features: (1)built-iintegral heat sink; (2)ul recognitioavailable; (3)up to 400 amp surge overload rating; (4)optioof wire leads or fastoterminals.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
KBPC35-10 |
Other |
Data Sheet |
Negotiable |
|
||||||
KBPC35-10W |
Other |
Data Sheet |
Negotiable |
|
