Product Summary
The SWG-B15 is a Planar Schottky barrier diode. The SWG-B15 is encapsulated in the SOT-323 small plastic SMD package. Single diodes and dual diodes with different pin configuration are available.
Parametrics
SWG-B15 absolute maximum ratings: (1)Continuous Reverse Voltage VR: 30 V; (2)Continuous Forward Current IF: 200 mA; (3)Repetitive Peak Forward Current (tP <1s, δ≤0.5)IFRM: 300 mA; (4)Non-repetitive Peak Forward Current (tP <10ms)IFSM: 600 mA; (5)Junction Temperature TJ: +125 °C; (6)Storage Temperature TSTG: -60 ~ +150 °C.
Features
SWG-B15 features: (1)Low forward voltage; (2)Guard ring protected; (3)Small plastic SMD package .
Diagrams
