Product Summary

The PIC627 is a Microsemi ESP Switching Regulator. The PIC627 is designed, constructed and specified for use in high current switching regulator applications. The designer of the PIC627 is thus relieved of one of the most time consuming, tedious and critical aspects of switching regulator design: choosing the appropriate switching transistors and commutating diode and empirically determining the optimum drive and bias conditions.

Parametrics

PIC627 absolute maximum ratings: (1)Input Voltage: 100 V; (2)Output Voltage: 100 V; (3)Drive-Input Reverse Voltage: 5 V; (4)Output Current: 15 A; (5)Drive Current: -0.4 A; (6)Power Switch: 4.0 ℃/W; (7)Commutating Diode: 4.0 ℃/W; (8)Case to Ambient: 60.0 ℃/W; (9)Operating Temperature Range: -55 to 125 ℃; (10)Maximum Junction Temperature: 150 ℃; (11)Storage temperature Range: -65 to 150 ℃.

Features

PIC627 features: (1)Designed and characterized for swiching regulator applications; (2)Cost saving design reduces size, improves efficiency, reduces noise and RFI; (3)High operating frequency results in smiller inductor-capacitor tilter and improved power supply response time; (4)High operating efficiency: Typical 7A circuit performance Rise and Fall time ＜ 300 ns Efficiency ＞ 85 %; (5)No reverse recovery spike generated by commutating diode; (6)Electrically isolated, 4-pin, TO66 hermetic case.

Diagrams

PIC627 block diagram
