Product Summary

The MC1554G is a 1-watt power amplifier. The MC1554G designed to amplify signals to 300-kHz with 1-watt Delivered to a direct coupled or capacitively coupled load.

Parametrics

MC1554G absolute maximum ratings: (1)Total Power Supply Voltage: 18 Vdc; (2)Peak Load Current: 0.5 Ampere; (3)Audio Output Power: 1.8 Watts; (4)Power Dissipation: 600 mW; (5)Operating Temperature Range: 0 to 70 ℃; (6)Storage Temperature Range: -55 to 150 ℃.

Features

MC1554G features: (1)Low Total Harmonic Distortion-0.4 % @ 1 Watt; (2)Low Output Impedance-0.2 Ohm; (3)Excellent Gain-Temperature Stability.

Diagrams

MC1554G block diagram
