AD9983AKCPZ-170

AD9983AKCPZ-170, monolithic analog interface, 1.98 V, 60 Hz, Analog Devices

Rated 5 Rating 5 | reviews | Write a review

Price:: US $8.50~9.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	9.00 / Piece
10 ~ 100 :	8.50 / Piece

PartNumber:: AD9983AKCPZ-170

Brand:: Analog Devices - ADI | Pack: QFP | D/C: 12+

Availability:: Supply Ability: 1/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Miki's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-15

From Other Seller

Part Number:AD9983AKCPZ-170
US $8.50 - 9.00
Quantity:

piece

Product Summary

The AD9983AKCPZ-170 is a complete 8-bit, 170 MSPS, monolithic analog interface optimized for capturing YPbPr video and RGB graphics signals. Its 170 MSPS encode rate capability and full power analog bandwidth of 300 MHz support all HDTV video modes up to 1080p as well as graphics resolutions up to UXGA (1600 × 1200 at 60 Hz). The AD9983AKCPZ-170 includes a 170 MHz triple ADC with an internal reference, a PLL, and programmable gain, offset, and clamp control. The user provides only a 1.8 V power supply and an analog input. Three-state CMOS outputs can be powered from 1.8 V to 3.3 V. The applications of the AD9983AKCPZ-170 include Advanced TVs,Plasma, display panels, LCDTV, HDTV, RGB graphics processing, LCD monitors and projectors, Scan converters.

Parametrics

AD9983AKCPZ-170 absolute maximum ratings: (1)VD: 1.98 V; (2)VDD: 3.6 V; (3)PVD: 1.98 V; (4)DAVDD: 1.98 V; (5)Analog Inputs: VD to 0.0 V; (6)REFHI: VD to 0.0 V ; (7)REFLO: VD to 0.0 V; (8)Digital Inputs: 5 V to 0.0 V ; (9)Digital Output Current: 20 mA ; (10)Operating Temperature: 25℃ to + 85℃; (11)Storage Temperature: 65℃ to + 150℃; (12)Maximum Junction Temperature: 150℃; (13)Maximum Case Temperature: 150℃.
