Product Summary

The AD844AN is a high speed monolithic operational amplifier. The AD844AN fabricated using Analog Devices’ junction isolated complementary bipolar (CB) process. The AD844AN combines high bandwidth and very fast large signal response with excellent dc performance. Although optimized for use in current to voltage applications and as an inverting mode amplifier, The AD844AN is also suitable for use in many noninverting applications. The applications of the AD844AN include Flash ADC Input Amplifiers, High Speed Current DAC Interfaces, Video Buffers and Cable Drivers, Pulse Amplifiers.

Parametrics

AD844AN absolute maximum ratings: (1)Supply Voltage: ±18 V; (2)Power Dissipation2: 1.1 W; (3)Output Short Circuit Duration: Indefinite; (4)Common-Mode Input Voltage: ±VS; (5)Differential Input Voltage: 6 V; (6)Inverting Input Current Continuous: 5 mA; (7)Transient: 10 mA; (8)Storage Temperature Range (Q): –65℃ to +150℃; (9)Storage Temperature Range (N, R): –65℃ to +125℃; (10)Lead Temperature Range (Soldering 60 sec): +300℃; (11)ESD Rating: 1000 V.

Features

AD844AN features: (1)Wide Bandwidth: 60 MHz at Gain of –1, 33 MHz at Gain of –10; (2)Very High Output Slew Rate: Up to 2000 V/μs; (3)20 MHz Full Power Bandwidth, 20 V pk-pk, RL = 500 Ω; (4)Fast Settling: 100 ns to 0.1% (10 V Step); (5)Differential Gain Error: 0.03% at 4.4 MHz; (6)Differential Phase Error: 0.15° at 4.4 MHz; (7)High Output Drive: ±50 mA into 50 Ω Load; (8)Low Offset Voltage: 150 μV max (B Grade); (9)Low Quiescent Current: 6.5 mA; (10)Available in Tape and Reel in Accordance with EIA-481A Standard.

Diagrams

AD844AN block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD844ANZ
AD844ANZ

IC OPAMP CF 60MHZ 80MA 8DIP
Data Sheet
0-1: $4.42
1-10: $3.97
10-25: $3.62
25-100: $3.27
100-250: $3.00
250-500: $2.74
500-1000: $2.38
1000-2500: $2.35
AD844AN
AD844AN

IC OPAMP CF 60MHZ 80MA 8DIP
Data Sheet
0-50: $3.99
